Duplex Service drop wire 6AWG to 4/0 AWG

Ⅰ Applications

   Primarily used for overhead service applications such as street lighting,outdoor lighting,and temporary service for construction. To be used at voltages of 600V phase-to-phase or less and at conductor temperatures not to exceed 75℃ for polyethylene insulated conductors or 90℃ for cross-linked polyethylene(XLPE) insulated conductors.

Ⅱ Service drop cable meets or exceeds the following specifications:

1、 Aluminum Wire,1350-H19 for Electrical Purposes.

2、 Aluminum Conductors, Concentric-Lay-Stranded.

3、 Aluminum conductor, Concentric-Lay-Stranded,Coated Steel Reinforced (ACSR).

4、 Concentric-Lay-Stranded 6201 –T81 Conductors

Service drop cable meets or exceeds all applicable requirements of ANSI/ICEA S-76-474
